Crystals

Type Characteristics Applications
Lithium Niobate Crystal
(LiNbO3, LN Crystal)
Strong nonlinearity, wide transparency range from 420 nm to 5.2 μm, and excellent nonlinear, electro - optic and piezoelectric properties Nonlinear frequency conversion for wavelengths > 1 μm and electro - optic modulators (EOM, 500nm-3um, with a relatively high bandwidth) It is an anisotropic crystal, and its polarization direction has a significant influence on the efficiency. Thermal drift effect will occur, and temperature control is required for high-precision applications.
Lithium Tantalate Crystal
 (LiTaO3, LT Crystal)
High chemical stability, low dielectric loss, high detectivity figure - of - merit, and very good electro - optic, piezoelectric and pyroelectric properties Materials for pyroelectric infrared detectors, resonators, filters, transducers, etc. Also used in optical Windows (~250 nm - 5 µm); If it is used as an electro-optic modulator, the electro-optic coefficient is slightly worse than that of Lithium Niobate Crystal , but the damage threshold is higher and the temperature drift is smaller.
Periodically Poled Lithium Niobate Crystal
(LiNbO3, PPLN Crystal)
High nonlinear d - coefficient, no walk - off property, relatively low damage threshold Widely used in devices for nonlinear frequency conversion, biology, material analysis, femtosecond lasers, terahertz, etc. Its SHG conversion efficiency is very high. But high-precision temperature control is required. The price is relatively low.
Periodically Stoichiometric Lithium Tantalate Crystal (LiTaO3, PPSLT Crystal) High damage threshold, high nonlinear coefficient, high thermal conductivity, high photorefractive coefficient Suitable for visible light generation applications, especially high - power green light generation. But medium and high precision temperature control is required; The SHG conversion efficiency is better than that of PPKTP but slightly worse than that of PPLN.
Potassium Titanyl Phosphate Crystal
 (KTiOPO4, KTP Crystal)
High nonlinearity, high mechanical stability, high optical quality, and transparency range from 350 nm to 4.5 μm Suitable for periodic polarization, medium and low power frequency doubling of neodymium-doped DPSS lasers, and nonlinear OPO media
Periodically Poled Potassium Titanyl Phosphate Crystal
(KTiOPO4, PPKTP Crystal)
Supports all nonlinear applications within the transparency range of KTP; no phase - matching limitations of KTP; effective nonlinear coefficient is three times that of KTP Frequency - doubling (SHG) devices at 1064 nm and 946 nm, OPO devices, etc. Its SHG conversion efficiency is very high, but slightly lower than that of PPLN. However, it has a very low temperature dependence and does not require temperature control.
Potassium Dihydrogen Phosphate Crystal
 (KH2PO4, KDP Crystal)
Excellent ultraviolet transmittance, high laser damage threshold, relatively low nonlinearity, can grow in large size, high hygroscopicity Frequency multiplier for neodymium-doped DPSS lasers, triplers and quadruplers for neodymium - doped lasers; Q - switches for Ti:sapphire, emerald, neodymium - doped lasers
Potassium Niobate Crystal
 (KNbO3, KN Crystal)
High nonlinearity(Similar to KTP), wide transparency range (0.4 - 5 mm), unaffected by photorefractive effect, and low damage threshold. Electro - optics and nonlinear optics, photorefractive applications of laser diodes, dynamic holography and optical phase - conjugate optical waveguides in near - infrared, optical second - harmonic generation (SHG), frequency doublers (Similar to KTP)
Potassium Titanyl Arsenate Crystal
 (KTiOAsO4, KTA Crystal)
Good nonlinear optical and electro - optical properties(Similar to KTP), significantly reduced absorption in the wavelength range of 2.0 - 5.0 μm, wide angular and temperature bandwidth, low dielectric constant OPO for mid - infrared generation - up to 4 μm; sum - and difference - frequency generation in the mid - infrared range; electro - optical modulation and Q - switching
Rubidium Titanyl Phosphate Crystal
 (RbTiOPO4, RTP Crystal)
Wide transparency range; stable mechanical and chemical properties; high damage threshold, high - temperature stability, low half - wave voltage, suitable for high - frequency operation, and fast response Electro - optical modulators, electro - optical Q - switches
Lithium Triborate Crystal
 (LiB3O5, LBO Crystal)
Wide transmission band, good ultraviolet transmittance, slight deliquescence, good physical and chemical properties, moderate nonlinear optical coefficient, good optical uniformity, high damage threshold, large acceptance angle and small walk - off angle, low temperature dependence and no need for temperature control. High - power near - infrared second - harmonic generation, sum - frequency generation to produce visible ultraviolet lasers, and widely tunable optical parametric oscillators in the visible near - infrared range
Cesium Lithium Borate Crystal
(CsLiB6O10, CLBO Crystal)
Sufficiently large nonlinear coefficient, short absorption edge, large angular, spectral and temperature bandwidths and other nonlinear optical characteristics, as well as extremely high damage thresholds. Well - suited for second - order and higher - order harmonic generation. It is an excellent material for fabricating ultraviolet and deep - ultraviolet all - solid - state lasers. With a CLBO - frequency - quadrupled YAG laser, the 266nm ultraviolet light output has reached 42 watts, and the femtosecond laser from mid-infrared to UV
Barium Metaborate Crystal
 (β−BaB2O4, BBO Crystal)
High nonlinear optical coefficient, low group velocity dispersion, broad transparency range (189 - 3500 nm) and high damage threshold, with the highest nonlinearity in the ultraviolet range Harmonic generation and frequency doubling of pulsed Yb - doped crystal lasers, third - harmonic generation of Ti:sapphire lasers, and widely tunable Type - I and Type - II OPOs
Yttrium Calcium Oxoborate Crystal
(YCa4O(BO3)3, YCOB Crystal)
The nonlinear optical coefficient is equivalent to that of BBO crystal and LBO crystal. The second - and third - order effective frequency - doubling coefficients reach 2.8 and 1.4 times that of KDP respectively. It has a large aperture, high damage strength in the femtosecond region, stable physical and chemical properties, and good processing performance. Ultraviolet - band optical frequency doubler
Zinc Germanium Phosphide Crystal
(ZnGeP2, ZGP Crystal)
It has the largest nonlinear coefficient among infrared crystals. The effective transmission range is from 2 μm to 12 μm. It has a relatively high damage threshold. The nominal absorption coefficient of the o - wave at ~2.1 μm is < 0.04 cm⁻¹. Harmonic generation of the fundamental waves of CO₂ and CO lasers; Generation of continuously tunable radiation in the MWIR and LWIR ranges through OPO and DFG technologies; Generation of frequencies in the terahertz range
Silver Gallium Selenide Crystal
(AgGaSe2, AGSe Crystal)
It shows excellent performance within the transmission range of 0.73 to 18 μm. It has low light absorption and scattering, and a high FOM (Figure of Merit). It is used for nonlinear interactions in NIR and MIR. Frequency mixing in the infrared region from 4.0 to 18.3 μm; Second - harmonic generation and up - conversion of CO₂ lasers; Tunable OPO for solid - state lasers with an efficiency of up to 10%
Silver Gallium Sulfide Crystal
 (AgGaS2, AGS Crystal)
Has unique nonlinear characteristics within the transmission range of 0.5 to 12 μm; low light absorption and scattering; short - wavelength transparency The mixing range in the intermediate IR region is 4.0 to 18.3 μm; second - harmonic generation and up - conversion of CO₂ lasers; suitable for tunable OPO of solid - state lasers
Gallium Selenide Crystal
(GaSe, GaSe Crystal)
Extremely soft, unable to be polished or coated; transparency range of 900 - 16000 nm; can only be cut along (001); due to high refractive index and directional limitations, can only use a small Theta angle; a cheaper alternative to AGS or AGSe High - power femtosecond lasers; terahertz (THz) generation(Terahertz window sheet); an alternative solution for generating broadband mid - infrared (MIR) electromagnetic waves; for CO, CO₂ and other lasers, second - harmonic generation (SHG) in the mid - infrared (MIR); optical parametric generation (OPG) within 3 - 16 μm
Cadmium Selenide Crystal
 (CdSe, CdSe Crystal)
Low light absorption; broadband specific transmission range: 2.5 μm to 16 μm Far - infrared wavelength radiation generated by DFG and OPO schemes; materials for infrared optical elements: substrates, polarizers, wave plates, etc.
