Confocal Microscopes
SIMTRUM Manufactur microscope related systems and solutions, our main focus is on confocal microscope system, below is the systems or solutions we produced. if you need customized system please contact us
| Parameters |
Basic P Series |
Advance P Series |
Basic L Series |
Advance L Series |
SpinDisk Basic |
SpinDisk Advance |
SIM Basic |
SpinDisk SIM |
| Image Frame Rate |
4fps@512x512 |
8-12fps@512x512 |
12fps@1024x1024 |
50fps@1024x1024 |
100fps@2048x2048 |
100fps@2048x2048 |
13fps@1024x1024 |
13fps@1024x1024 |
| Resolution |
~230 nm |
~230 nm |
~230 nm |
150-200nm |
~230 nm |
~230 nm |
~100 nm |
~100 nm |
| Image Depth |
<100µm |
<100µm |
<100µm |
<600µm |
<200µm |
<200µm |
<50µm |
<200µm |
| No. of Laser |
1 |
4 |
1 |
4 |
4 |
4 |
4 |
4 |
| Wavelength |
Available Choice 405 / 445 / 488 / 525 / 561 / 640(nm) | Customized Wavelength available |
| Detectors |
Detector |
Detector |
CMOS Camera |
sCMOS Camera |
sCMOS Camera |
Dual sCMOS Camera |
sCMOS Camera |
Dual sCMOS Camera |
| Microscope |
Inverted (Upright Customizeable) |
Inverted (Upright Customizeable) |
Inverted (Upright Customizeable) |
Inverted (Upright Customizeable) |
Inverted or Upright |
Inverted or Upright |
Inverted or Upright |
Inverted |
| Stages |
Z Motorized XY Manual |
XYZ Motorized |
Z Motorized
XY Manual |
XYZ Motorized |
XYZ Motorized |
XYZ Motorized |
XYZ Motorized |
XYZ Motorized |
| image contrast |
Medium |
High |
Medium |
High |
High |
High |
High |
High |
Technical Support Available: Contact us | You can download our full Product Line Card Click Here
