BBO

LBO Nonlinear Optical Crystal.jpg

BBO(Barium Borate) is a versatile non-linear crystal with various properties such as high broad phase-matching range, wide transmission region between 190-3500nm , large effective second-harmonic-generation(SHG) that is much greater than KDP crystal, and high damage threshold.


The crystal can exist in two forms, the α form and the β form, with the beta phase converting into the alpha phase at ~925°C. Both phases are birefringent. BBO has uses in frequency conversion of laser sources, optical parametric oscillators, and in electro- optical applications from the near IR to the deep UV region. The crystal shown is the β form.



General Specifications

Material

BBO

Dimension Tolerance(mm)

±0.1

Surface Quality

10/5

Flatness

λ/10

Wavefront Distortion

λ/8

Parallelism(arcsec)

20

Damage Threshold(pulsed)

5 GW/cm2 (10 ns) @1064nm

1 GW/cm2 (10 ns) @532 nm

Mount

Unmounted

Typical Application

SHG @ 800 nm





image.png                   image.png

                                                                                         Figure 1                                                                                                                                   Figure 2


image.png                   image.png

                                                                                           Figure 3                                                                                                                                Figure 4



                                                                                                                                                                 Figure 5


Working wavelength range, µm

0.8 – 1.2

Ground state absorption cross section, cm²

5×10-18 (at 1.06 µm)

Excited state absorption cross-section, cm²

7×10-19 (at 1.06 μm)

Initial transmittance, %

20 – 99

Transmission tolerances

±2 %

Wavefront distortion

<λ/8@633nm

Diameter tolerances

+0.0 / -0.2 mm

Parallelism error

≤ 30 arcsec

Perpendicularity

≤ 15 arcmin

Surface quality

20 – 10

Chamfer

<0.1mm@45°

AR Coating reflectivity

<0.2%@1064nm



Automatic Quotation Generation (Recommended)

To generate an automatic quotation request please login using the Sign In button (top right of the screen).

New users will be given the opportunity to register. Join our mailing list and follow us on linkedin for constant updates.


Technical Assistance and Email Quotations (Recommended for Custom Orders, inquiries)

For technical assistance, custom orders or email quotations, drop us an email at info@simtrum.com.

We will get back to you within 3 working days.


Local Same Day Service

SINGAPORE: For same day service, please contact us at 6996 0391. Office Hours: 9am - 6pm (+8GMT)

For more contact information click here.


International Inquiries

SIMTRUM provides worldwide shipping and inquiry management. Please contact us for more information.


Thickness (mm)

Dimension (mm)


Search Reset
Compare Model Drawings & Specs Coating Dimension (mm) Thickness (mm) Orientation (Θ/φ) (°) Availability Price
(USD)
BBO-NLC-29.2/0-6-0.05-P
Type I BBO Nonlinear Crystal, 6x6, SHG@800nm
P-coating @800&400nm6x60.0529.2/0 In Stock $550.00
BBO-NLC-29.2/0-6-0.1-P
Type I BBO Nonlinear Crystal, 6x6, SHG@800nm
P-coating @800&400nm6x60.129.2/0 In Stock $420.00
BBO-NLC-29.2/0-6-0.2-P
Type I BBO Nonlinear Crystal, 6x6, SHG@800nm
P-coating @800&400nm6x60.229.2/0 In Stock $360.00
BBO-NLC-29.2/0-6-0.5-P
Type I BBO Nonlinear Crystal, 6x6, SHG@800nm
P-coating @800&400nm6x60.529.2/0 In Stock $360.00
BBO-NLC-29.2/0-6-1-P
Type I BBO Nonlinear Crystal, 6x6, SHG@800nm
P-coating @800&400nm6x6129.2/0 In Stock $350.00
BBO-NLC-29.2/0-6-2-P
Type I BBO Nonlinear Crystal, 6x6, SHG@800nm
P-coating @800&400nm6x6229.2/0 In Stock $350.00
BBO-NLC-29.2/0-10-0.05-P
Type I BBO Nonlinear Crystal, 10x10, SHG@800nm
P-coating @800&400nm10x100.0529.2/0 In Stock $700.00
BBO-NLC-29.2/0-10-0.1-P
Type I BBO Nonlinear Crystal, 10x10, SHG@800nm
P-coating @800&400nm10x100.129.2/0 In Stock $600.00
BBO-NLC-29.2/0-10-0.2-P
Type I BBO Nonlinear Crystal, 10x10, SHG@800nm
P-coating @800&400nm10x100.229.2/0 In Stock $560.00
BBO-NLC-29.2/0-10-0.5-P
Type I BBO Nonlinear Crystal, 10x10, SHG@800nm
P-coating @800&400nm10x100.529.2/0 In Stock $560.00
BBO-NLC-29.2/0-10-1-P
Type I BBO Nonlinear Crystal, 10x10, SHG@800nm
P-coating @800&400nm10x10129.2/0 In Stock $560.00
BBO-NLC-29.2/0-10-2-P
Type I BBO Nonlinear Crystal, 10x10, SHG@800nm
P-coating @800&400nm10x10229.2/0 In Stock $560.00
BBO-NLC-44.3/0-6-0.1-P
Type I BBO Nonlinear Crystal, 6x6, SHG@800nm
P-coating @800&400nm6x60.144.3/0 In Stock $420.00
BBO-NLC-44.3/0-6-0.2-P
Type I BBO Nonlinear Crystal, 6x6, SHG@800nm
P-coating @800&400nm6x60.244.3/0 In Stock $360.00
BBO-NLC-44.3/0-6-0.5-P
Type I BBO Nonlinear Crystal, 6x6, SHG@800nm
P-coating @800&400nm6x60.544.3/0 In Stock $360.00
BBO-NLC-44.3/0-6-1-P
Type I BBO Nonlinear Crystal, 6x6, SHG@800nm
P-coating @800&400nm6x6144.3/0 In Stock $360.00
BBO-NLC-44.3/0-10-0.1-P
Type I BBO Nonlinear Crystal, 10x10, SHG@800nm
P-coating @800&400nm10x100.144.3/0 In Stock $620.00
BBO-NLC-44.3/0-10-0.2-P
Type I BBO Nonlinear Crystal, 10x10, SHG@800nm
P-coating @800&400nm10x100.244.3/0 In Stock $560.00
BBO-NLC-44.3/0-10-0.5-P
Type I BBO Nonlinear Crystal, 10x10, SHG@800nm
P-coating @800&400nm10x100.544.3/0 In Stock $560.00
BBO-NLC-44.3/0-10-1-P
Type I BBO Nonlinear Crystal, 10x10, SHG@800nm
P-coating @800&400nm10x10144.3/0 In Stock $560.00
BBO-NLC-23.4/0-6-0.5-P
Type I BBO Nonlinear Crystal, 6x6, SHG@800nm
P-coating @1030&515nm6x60.523.4/0 In Stock $360.00
BBO-NLC-23.4/0-6-1-P
Type I BBO Nonlinear Crystal, 6x6, SHG@800nm
P-coating @1030&515nm6x6123.4/0 In Stock $360.00
BBO-NLC-23.4/0-6-1.5-P
Type I BBO Nonlinear Crystal, 6x6, SHG@800nm
P-coating @1030&515nm6x61.523.4/0 In Stock $360.00
BBO-NLC-23.4/0-6-2-P
Type I BBO Nonlinear Crystal, 6x6, SHG@800nm
P-coating @1030&515nm6x6223.4/0 In Stock $360.00

BBO-NLC-23.4/0-6-2-P - Parameter

Material
BBO

Coating
P-coating @1030&515nm

Thickness Tolerance (mm)
± 0.1

Surface Quality
10/5

Damage Threshold (pulsed)
5 GW/cm2 (10 ns) @1064nm, 1 GW/cm2 (10 ns) @532 nm

Dimension (mm)
6x6

Dimensional Tolerance (mm)
±0.1

Thickness (mm)
2

Flatness
λ/10

Wavefront Distortion
λ/8

Parallelism (arcsec)
20

Mount
Unmounted

Orientation (Θ/φ) (°)
23.4/0

Typical Applications
SHG@800nm

BBO-NLC-23.4/0-6-1.5-P - Parameter

Material
BBO

Coating
P-coating @1030&515nm

Thickness Tolerance (mm)
± 0.1

Surface Quality
10/5

Damage Threshold (pulsed)
5 GW/cm2 (10 ns) @1064nm, 1 GW/cm2 (10 ns) @532 nm

Dimension (mm)
6x6

Dimensional Tolerance (mm)
±0.1

Thickness (mm)
1.5

Flatness
λ/10

Wavefront Distortion
λ/8

Parallelism (arcsec)
20

Mount
Unmounted

Orientation (Θ/φ) (°)
23.4/0

Typical Applications
SHG@800nm

BBO-NLC-23.4/0-6-1-P - Parameter

Material
BBO

Coating
P-coating @1030&515nm

Thickness Tolerance (mm)
± 0.1

Surface Quality
10/5

Damage Threshold (pulsed)
5 GW/cm2 (10 ns) @1064nm, 1 GW/cm2 (10 ns) @532 nm

Dimension (mm)
6x6

Dimensional Tolerance (mm)
±0.1

Thickness (mm)
1

Flatness
λ/10

Wavefront Distortion
λ/8

Parallelism (arcsec)
20

Mount
Unmounted

Orientation (Θ/φ) (°)
23.4/0

Typical Applications
SHG@800nm

BBO-NLC-23.4/0-6-0.5-P - Parameter

Material
BBO

Coating
P-coating @1030&515nm

Thickness Tolerance (mm)
± 0.1

Surface Quality
10/5

Damage Threshold (pulsed)
5 GW/cm2 (10 ns) @1064nm, 1 GW/cm2 (10 ns) @532 nm

Dimension (mm)
6x6

Dimensional Tolerance (mm)
±0.1

Thickness (mm)
0.5

Flatness
λ/10

Wavefront Distortion
λ/8

Parallelism (arcsec)
20

Mount
Unmounted

Orientation (Θ/φ) (°)
23.4/0

Typical Applications
SHG@800nm

BBO-NLC-44.3/0-10-1-P - Parameter

Material
BBO

Coating
P-coating @800&400nm

Thickness Tolerance (mm)
± 0.1

Surface Quality
10/5

Damage Threshold (pulsed)
5 GW/cm2 (10 ns) @1064nm, 1 GW/cm2 (10 ns) @532 nm

Dimension (mm)
10x10

Dimensional Tolerance (mm)
±0.1

Thickness (mm)
1

Flatness
λ/10

Wavefront Distortion
λ/8

Parallelism (arcsec)
20

Mount
Unmounted

Orientation (Θ/φ) (°)
44.3/0

Typical Applications
SHG@800nm

BBO-NLC-44.3/0-10-0.5-P - Parameter

Material
BBO

Coating
P-coating @800&400nm

Thickness Tolerance (mm)
± 0.1

Surface Quality
10/5

Damage Threshold (pulsed)
5 GW/cm2 (10 ns) @1064nm, 1 GW/cm2 (10 ns) @532 nm

Dimension (mm)
10x10

Dimensional Tolerance (mm)
±0.1

Thickness (mm)
0.5

Flatness
λ/10

Wavefront Distortion
λ/8

Parallelism (arcsec)
20

Mount
Unmounted

Orientation (Θ/φ) (°)
44.3/0

Typical Applications
SHG@800nm

BBO-NLC-44.3/0-10-0.2-P - Parameter

Material
BBO

Coating
P-coating @800&400nm

Thickness Tolerance (mm)
± 0.1

Surface Quality
10/5

Damage Threshold (pulsed)
5 GW/cm2 (10 ns) @1064nm, 1 GW/cm2 (10 ns) @532 nm

Dimension (mm)
10x10

Dimensional Tolerance (mm)
±0.1

Thickness (mm)
0.2

Flatness
λ/10

Wavefront Distortion
λ/8

Parallelism (arcsec)
20

Mount
Unmounted

Orientation (Θ/φ) (°)
44.3/0

Typical Applications
SHG@800nm

BBO-NLC-44.3/0-10-0.1-P - Parameter

Material
BBO

Coating
P-coating @800&400nm

Thickness Tolerance (mm)
± 0.1

Surface Quality
10/5

Damage Threshold (pulsed)
5 GW/cm2 (10 ns) @1064nm, 1 GW/cm2 (10 ns) @532 nm

Dimension (mm)
10x10

Dimensional Tolerance (mm)
±0.1

Thickness (mm)
0.1

Flatness
λ/10

Wavefront Distortion
λ/8

Parallelism (arcsec)
20

Mount
Unmounted

Orientation (Θ/φ) (°)
44.3/0

Typical Applications
SHG@800nm

BBO-NLC-44.3/0-6-1-P - Parameter

Material
BBO

Coating
P-coating @800&400nm

Thickness Tolerance (mm)
± 0.1

Surface Quality
10/5

Damage Threshold (pulsed)
5 GW/cm2 (10 ns) @1064nm, 1 GW/cm2 (10 ns) @532 nm

Dimension (mm)
6x6

Dimensional Tolerance (mm)
±0.1

Thickness (mm)
1

Flatness
λ/10

Wavefront Distortion
λ/8

Parallelism (arcsec)
20

Mount
Unmounted

Orientation (Θ/φ) (°)
44.3/0

Typical Applications
SHG@800nm

BBO-NLC-44.3/0-6-0.5-P - Parameter

Material
BBO

Coating
P-coating @800&400nm

Thickness Tolerance (mm)
± 0.1

Surface Quality
10/5

Damage Threshold (pulsed)
5 GW/cm2 (10 ns) @1064nm, 1 GW/cm2 (10 ns) @532 nm

Dimension (mm)
6x6

Dimensional Tolerance (mm)
±0.1

Thickness (mm)
0.5

Flatness
λ/10

Wavefront Distortion
λ/8

Parallelism (arcsec)
20

Mount
Unmounted

Orientation (Θ/φ) (°)
44.3/0

Typical Applications
SHG@800nm

BBO-NLC-44.3/0-6-0.2-P - Parameter

Material
BBO

Coating
P-coating @800&400nm

Thickness Tolerance (mm)
± 0.1

Surface Quality
10/5

Damage Threshold (pulsed)
5 GW/cm2 (10 ns) @1064nm, 1 GW/cm2 (10 ns) @532 nm

Dimension (mm)
6x6

Dimensional Tolerance (mm)
±0.1

Thickness (mm)
0.2

Flatness
λ/10

Wavefront Distortion
λ/8

Parallelism (arcsec)
20

Mount
Unmounted

Orientation (Θ/φ) (°)
44.3/0

Typical Applications
SHG@800nm

BBO-NLC-44.3/0-6-0.1-P - Parameter

Material
BBO

Coating
P-coating @800&400nm

Thickness Tolerance (mm)
± 0.1

Surface Quality
10/5

Damage Threshold (pulsed)
5 GW/cm2 (10 ns) @1064nm, 1 GW/cm2 (10 ns) @532 nm

Dimension (mm)
6x6

Dimensional Tolerance (mm)
±0.1

Thickness (mm)
0.1

Flatness
λ/10

Wavefront Distortion
λ/8

Parallelism (arcsec)
20

Mount
Unmounted

Orientation (Θ/φ) (°)
44.3/0

Typical Applications
SHG@800nm

BBO-NLC-29.2/0-10-2-P - Parameter

Material
BBO

Coating
P-coating @800&400nm

Thickness Tolerance (mm)
± 0.1

Surface Quality
10/5

Damage Threshold (pulsed)
5 GW/cm2 (10 ns) @1064nm, 1 GW/cm2 (10 ns) @532 nm

Dimension (mm)
10x10

Dimensional Tolerance (mm)
±0.1

Thickness (mm)
2

Flatness
λ/10

Wavefront Distortion
λ/8

Parallelism (arcsec)
20

Mount
Unmounted

Orientation (Θ/φ) (°)
29.2/0

Typical Applications
SHG@800nm

BBO-NLC-29.2/0-10-1-P - Parameter

Material
BBO

Coating
P-coating @800&400nm

Thickness Tolerance (mm)
± 0.1

Surface Quality
10/5

Damage Threshold (pulsed)
5 GW/cm2 (10 ns) @1064nm, 1 GW/cm2 (10 ns) @532 nm

Dimension (mm)
10x10

Dimensional Tolerance (mm)
±0.1

Thickness (mm)
1

Flatness
λ/10

Wavefront Distortion
λ/8

Parallelism (arcsec)
20

Mount
Unmounted

Orientation (Θ/φ) (°)
29.2/0

Typical Applications
SHG@800nm

BBO-NLC-29.2/0-10-0.5-P - Parameter

Material
BBO

Coating
P-coating @800&400nm

Thickness Tolerance (mm)
± 0.1

Surface Quality
10/5

Damage Threshold (pulsed)
5 GW/cm2 (10 ns) @1064nm, 1 GW/cm2 (10 ns) @532 nm

Dimension (mm)
10x10

Dimensional Tolerance (mm)
±0.1

Thickness (mm)
0.5

Flatness
λ/10

Wavefront Distortion
λ/8

Parallelism (arcsec)
20

Mount
Unmounted

Orientation (Θ/φ) (°)
29.2/0

Typical Applications
SHG@800nm

BBO-NLC-29.2/0-10-0.2-P - Parameter

Material
BBO

Coating
P-coating @800&400nm

Thickness Tolerance (mm)
± 0.1

Surface Quality
10/5

Damage Threshold (pulsed)
5 GW/cm2 (10 ns) @1064nm, 1 GW/cm2 (10 ns) @532 nm

Dimension (mm)
10x10

Dimensional Tolerance (mm)
±0.1

Thickness (mm)
0.2

Flatness
λ/10

Wavefront Distortion
λ/8

Parallelism (arcsec)
20

Mount
Unmounted

Orientation (Θ/φ) (°)
29.2/0

Typical Applications
SHG@800nm

BBO-NLC-29.2/0-10-0.1-P - Parameter

Material
BBO

Coating
P-coating @800&400nm

Thickness Tolerance (mm)
± 0.1

Surface Quality
10/5

Damage Threshold (pulsed)
5 GW/cm2 (10 ns) @1064nm, 1 GW/cm2 (10 ns) @532 nm

Dimension (mm)
10x10

Dimensional Tolerance (mm)
±0.1

Thickness (mm)
0.1

Flatness
λ/10

Wavefront Distortion
λ/8

Parallelism (arcsec)
20

Mount
Unmounted

Orientation (Θ/φ) (°)
29.2/0

Typical Applications
SHG@800nm

BBO-NLC-29.2/0-10-0.05-P - Parameter

Material
BBO

Coating
P-coating @800&400nm

Thickness Tolerance (mm)
± 0.1

Surface Quality
10/5

Damage Threshold (pulsed)
5 GW/cm2 (10 ns) @1064nm, 1 GW/cm2 (10 ns) @532 nm

Dimension (mm)
10x10

Dimensional Tolerance (mm)
±0.1

Thickness (mm)
0.05

Flatness
λ/10

Wavefront Distortion
λ/8

Parallelism (arcsec)
20

Mount
Unmounted

Orientation (Θ/φ) (°)
29.2/0

Typical Applications
SHG@800nm

BBO-NLC-29.2/0-6-2-P - Parameter

Material
BBO

Coating
P-coating @800&400nm

Thickness Tolerance (mm)
± 0.1

Surface Quality
10/5

Damage Threshold (pulsed)
5 GW/cm2 (10 ns) @1064nm, 1 GW/cm2 (10 ns) @532 nm

Dimension (mm)
6x6

Dimensional Tolerance (mm)
±0.1

Thickness (mm)
2

Flatness
λ/10

Wavefront Distortion
λ/8

Parallelism (arcsec)
20

Mount
Unmounted

Orientation (Θ/φ) (°)
29.2/0

Typical Applications
SHG@800nm

BBO-NLC-29.2/0-6-1-P - Parameter

Material
BBO

Coating
P-coating @800&400nm

Thickness Tolerance (mm)
± 0.1

Surface Quality
10/5

Damage Threshold (pulsed)
5 GW/cm2 (10 ns) @1064nm, 1 GW/cm2 (10 ns) @532 nm

Dimension (mm)
6x6

Dimensional Tolerance (mm)
±0.1

Thickness (mm)
1

Flatness
λ/10

Wavefront Distortion
λ/8

Parallelism (arcsec)
20

Mount
Unmounted

Orientation (Θ/φ) (°)
29.2/0

Typical Applications
SHG@800nm

BBO-NLC-29.2/0-6-0.5-P - Parameter

Material
BBO

Coating
P-coating @800&400nm

Thickness Tolerance (mm)
± 0.1

Surface Quality
10/5

Damage Threshold (pulsed)
5 GW/cm2 (10 ns) @1064nm, 1 GW/cm2 (10 ns) @532 nm

Dimension (mm)
6x6

Dimensional Tolerance (mm)
±0.1

Thickness (mm)
0.5

Flatness
λ/10

Wavefront Distortion
λ/8

Parallelism (arcsec)
20

Mount
Unmounted

Orientation (Θ/φ) (°)
29.2/0

Typical Applications
SHG@800nm

BBO-NLC-29.2/0-6-0.2-P - Parameter

Material
BBO

Coating
P-coating @800&400nm

Thickness Tolerance (mm)
± 0.1

Surface Quality
10/5

Damage Threshold (pulsed)
5 GW/cm2 (10 ns) @1064nm, 1 GW/cm2 (10 ns) @532 nm

Dimension (mm)
6x6

Dimensional Tolerance (mm)
±0.1

Thickness (mm)
0.2

Flatness
λ/10

Wavefront Distortion
λ/8

Parallelism (arcsec)
20

Mount
Unmounted

Orientation (Θ/φ) (°)
29.2/0

Typical Applications
SHG@800nm

BBO-NLC-29.2/0-6-0.1-P - Parameter

Material
BBO

Coating
P-coating @800&400nm

Thickness Tolerance (mm)
± 0.1

Surface Quality
10/5

Damage Threshold (pulsed)
5 GW/cm2 (10 ns) @1064nm, 1 GW/cm2 (10 ns) @532 nm

Dimension (mm)
6x6

Dimensional Tolerance (mm)
±0.1

Thickness (mm)
0.1

Flatness
λ/10

Wavefront Distortion
λ/8

Parallelism (arcsec)
20

Mount
Unmounted

Orientation (Θ/φ) (°)
29.2/0

Typical Applications
SHG@800nm

BBO-NLC-29.2/0-6-0.05-P - Parameter

Material
BBO

Coating
P-coating @800&400nm

Thickness Tolerance (mm)
± 0.1

Surface Quality
10/5

Damage Threshold (pulsed)
5 GW/cm2 (10 ns) @1064nm, 1 GW/cm2 (10 ns) @532 nm

Dimension (mm)
6x6

Dimensional Tolerance (mm)
±0.1

Thickness (mm)
0.05

Flatness
λ/10

Wavefront Distortion
λ/8

Parallelism (arcsec)
20

Mount
Unmounted

Orientation (Θ/φ) (°)
29.2/0

Typical Applications
SHG@800nm

BBO-NLC-23.4/0-6-2-P - Download

BBO-NLC-23.4/0-6-1.5-P - Download

BBO-NLC-23.4/0-6-1-P - Download

BBO-NLC-23.4/0-6-0.5-P - Download

BBO-NLC-44.3/0-10-1-P - Download

BBO-NLC-44.3/0-10-0.5-P - Download

BBO-NLC-44.3/0-10-0.2-P - Download

BBO-NLC-44.3/0-10-0.1-P - Download

BBO-NLC-44.3/0-6-1-P - Download

BBO-NLC-44.3/0-6-0.5-P - Download

BBO-NLC-44.3/0-6-0.2-P - Download

BBO-NLC-44.3/0-6-0.1-P - Download

BBO-NLC-29.2/0-10-2-P - Download

BBO-NLC-29.2/0-10-1-P - Download

BBO-NLC-29.2/0-10-0.5-P - Download

BBO-NLC-29.2/0-10-0.2-P - Download

BBO-NLC-29.2/0-10-0.1-P - Download

BBO-NLC-29.2/0-10-0.05-P - Download

BBO-NLC-29.2/0-6-2-P - Download

BBO-NLC-29.2/0-6-1-P - Download

BBO-NLC-29.2/0-6-0.5-P - Download

BBO-NLC-29.2/0-6-0.2-P - Download

BBO-NLC-29.2/0-6-0.1-P - Download

BBO-NLC-29.2/0-6-0.05-P - Download

Accessories

Motorized Actuator Adapters

Compare Model Drawings & Specs Availability Price
(USD)
