1064/1550nm Nanosecond Pulse Fiber Laser

SIMTRUM’s STNSFL series 1064nm Nanosecond Pulse Fiber Laser adopts unique circuit and optical optimization design. The pulse width, peak power and repetition frequency of the output laser are all adjustable. Single mode fiber output and modular packaging make the laser easy for system integration and suitable for distributed optical fiber sensing system applications.

Features

All-fiber structure
Pulse width, repetition rate, and power adjustable
Desktop or module packaging

Applications

Lidar
Nonlinear optics
Fiber optic sensing

Product specifications and Brochures

Product Brochure Link:

Optical Parameters	Unit	Typical Value	Remark
Center Wavelength	nm	1064±2
Spectral Width	nm	≤ 1
Pulse Peak Power	W	10 ~ 50 adjustable	Maximum power can be customized
Pulse Width	ns	2 ~ 50 adjustable
Pules Repetition Rate	kHz	1 ~ 1000 adjustable
Short-term Stability (15min)	dB	≤ ± 0.02	Power stability ≤ ± 0.5%
Long-term Stability (8hrs)	dB	≤ ± 0.05	Power stability ≤ ± 1.2%
Fiber Type	-	Hi-1060 SMF/ PM980 PMF
Fiber Connector Type	-	FC/APC

General Parameters	Desktop	Module
Control Function	Touchscreen / RS232 Serial Communication	Button/ RS232 or USB Communication
Remote Control Port	DB9 Female	DB9 Female
Trigger Method	TTL, Internal/External Trigger (Switchable)
Power Supply	AC100~240V, 30W	DC5V, 15W
Dimensions	255(W)×285(D)×115(H)mm	125 (W)×150(D)×20(H)mm
Operation Temperature	-5 ~ +35°C
Operation Humidity	0 ~ 70%

Ordering Information/Product Code
Series	Wavelength (nm)	Maximum Peak Power (W)	Fiber Type	Packaging
STNSFL	1064	10/30/50	SM = Hi-1060 PM = PM980	M - Module
				B - Desktop

SIMTRUM’s STNSFL series 1550nm Nanosecond Pulse Fiber Laser adopts unique circuit and optical optimization design. The pulse width, peak power and repetition frequency of the output laser are all adjustable. It features stable working wavelength and power output, single-mode fiber output, and a modular design that facilitates system integration. It is suitable for use in distributed fiber optic sensing systems.

Features

All-fiber structure
Pulse width, repetition rate, and power adjustable
Desktop or module packaging

Applications

Lidar
Nonlinear optics
Distributed fiber optic sensing DTS

Product specifications and Brochures

Product Brochure Link:

Optical Parameters	Unit	Typical Value	Remark
Center Wavelength	nm	1550±1
Spectral Width	nm	≤ 1
Pulse Peak Power	W	10 ~ 50 adjustable	Maximum power can be customized
Pulse Width	ns	3 ~ 50 adjustable
Pules Repetition Rate	kHz	1 ~ 100 adjustable
Short-term Stability (15min)	dB	≤ ± 0.02	Power stability ≤ ± 0.5%
Long-term Stability (8hrs)	dB	≤ ± 0.05	Power stability ≤ ± 1.2%
Tail Fiber Type	-	SMF-28
Tail Connector Type	-	FC/APC

General Parameters	Desktop	Module
Control Function	Touchscreen / RS232 Serial Communication	Button / RS232 or USB Communication
Remote Control Port	DB9 Female	DB9 Female
Trigger Method	TTL, Internal/External Trigger (Switchable)
Power Supply	AC100~240V, 30W	DC5V, 15W
Dimensions	255(W)×285(D)×115(H)mm	125(W)×150(D)×20(H)mm
Operation Temperature	-5 ~ +35°C
Operation Humidity	0~70%

Ordering Information/Product Code
Series	Wavelength (nm)	Maximum Peak Power (W)	Fiber	Packaging
STNSFL	1550	10/30/50	SM = SMF-28	M - Module
				B - Desktop

SIMTRUM’s 1550nm High-power Nanosecond Pulse Fiber Laser uses high-power gain fiber module and cooperates with special drive and temperature control circuit to output high peak value and high energy laser pulse, laser wavelength and power are stable. It can be used for laser ranging radar, fiber optic sensing system, etc.

Features

All-fiber structure
Pulse width, repetition rate, and power adjustable
Pulse energy up to 100uJ

Applications

Lidar ranging radar
Nonlinear optics
Fiber optic distributed sensing

Product specifications and Brochures

Product Brochure Link:

Optical Parameters	Unit	Typical Value	Remark
Working Wavelength	nm	1550
Wavelength Accuracy	nm	± 1
Maximum Single Pulse Energy	uJ	100	at Pulse Repetition Rate ≤ 10kHz, Pulse Width≥10ns
Maximum Peak Power	kW	10	at Pulse Width = 3ns, Pulse Repetition Rate ≤ 10kHz
Maximum Average Power	W	2	at Pulse Width = 3ns, Pulse Repetition Rate ≥100kHz
Pulse Width	ns	1 ~ 200 adjustable	*1~3ns have partial energy loss, >3ns have full energy
Repetition Rate	kHz	1 ~ 3000 adjustable
Beam Quality M²	-	≤ 1.1	Based on the output collimator specifications
Output Polarization	-	Random
Output Isolation	dB	≥ 30
Short-term Stability (15min)	dB	≤ ± 0.05	Power stability ≤ ± 1.2%
Long-term Stability (8hrs)	dB	≤ ± 0.1	Power stability ≤ ± 2%
Output Fiber Type	-	SMF-28 fiber
Output Connector Type	-	FC/APC	Depending on peak power

General Parameters	Desktop	Module
Control Function	Touchscreen / RS232 Serial Communication	Button/ RS232 or USB Communication
Remote Control Port	DB9 Female	DB9 Female
Modulation Method	TTL, Internal / External Modulation (Switchable)
Power Supply	AC100~240V, 30W	DC12V, 30W
Dimensions	255(W)×322(D)×115(H)mm	100(W)×100(D)×30(H)mm
Operation Temperature	-5 ~ +35°C
Operation Humidity	0 ~ 70%

Ordering Information/Product Code
Series	Wavelength (nm)	Pulse Width (ns)	Peak Power (kW)	Repetition Rate (kHz)	Fiber	Output Method	Packaging
STHP-NSFL-A	1550	1/3/10/100/200	1/5/10	1/100/1000	SM = SMF - 28	FA = FC/APC	M - Module
						C = Collimator	B - Desktop

We are here for you!


Drop us an email at info@simtrum.com to get the Best Price today.		Want more technical information? Click Here for the professional Customized System/ Solutions.


Don't have time to search the products one by one? No worries. you can download the full range of SIMTRUM Product Line Cards. Click it now.		Want to stay closer to the Market Dynamics and Technological Developments? Just take 5 seconds to Sign In as a member of SIMTRUM, we will bring you the most up-to-date news. (Sign in button on the top right of the screen).

	Availability	Reference Price (USD)
STNSFL-1064-10-SM-B Center wavelength 1064±2 nm, Pulse Peak Power 10W, Pulse Width 2-50 ns adjustable, Repetition Rate 1-1000 kHz adjustable, Fiber Type: SMF-28	4-6 Weeks	$3968.00
STNSFL-1064-30-SM-B Center wavelength 1064±2 nm, Pulse Peak Power 30W, Pulse Width 2-50 ns adjustable, Repetition Rate 1-1000 kHz adjustable, Fiber Type: SMF-28	4-6 Weeks	$4048.00
STNSFL-1064-50-SM-B Center wavelength 1064±2 nm, Pulse Peak Power 50W, Pulse Width 2-50 ns adjustable, Repetition Rate 1-1000 kHz adjustable, Fiber Type: SMF-28	4-6 Weeks	$4312.00
STNSFL-1550-10-SM-B Center wavelength 1550±1 nm, Pulse Peak Power 10W, Pulse Width 3-50 ns adjustable, Repetition Rate 1-100 kHz adjustable, Fiber Type: SMF-28	4-6 Weeks	$3386.00
STNSFL-1550-30-SM-B Center wavelength 1550±1 nm, Pulse Peak Power 30W, Pulse Width 3-50 ns adjustable, Repetition Rate 1-100 kHz adjustable, Fiber Type: SMF-28	4-6 Weeks	$3651.00
STNSFL-1550-50-SM-B Center wavelength 1550±1 nm, Pulse Peak Power 50W, Pulse Width 3-50 ns adjustable, Repetition Rate 1-100 kHz adjustable, Fiber Type: SMF-28	4-6 Weeks	$3915.00
STHP-NSFL-A-1550-3/200-10-1/3000-SM-FA-B 1550nm High-power Nanosecond Pulse Laser, wavelength 1550nm, wavelength accuracy ±1nm, average power maximum 2W@≥100kHz, pulse frequency 1~3000kHz adjustable, 10%~100% power range adjustable, SMF-28fiber, FC/APC Connector	4-6 Weeks	$5079.00
